2022 Club Car V4L Black Gas

Price

$11,059.00

Unit Number

25877

Speed

19 mph (30 kph)

Seating for

4

Powertrain

Gas

Engine

429 cc Kohler

The V4L can get you there. With the same suspension and rear seats as lifted Onwards, this vehicle is outfitted with premium comfort and quality. Summer night rides and sunrise cruises are safer, thanks to automotive quality headlights, tail lights, & brake lights with optional turn signals.

The V4L can get you there. With the same suspension and rear seats as lifted Onwards, this vehicle is outfitted with premium comfort and quality. Summer night rides and sunrise cruises are safer, thanks to automotive quality headlights, tail lights, & brake lights with optional turn signals.

Price

$11,059.00

Unit Number

25877

Speed

19 mph (30 kph)

Seating for

4

Powertrain

Gas

Engine

429 cc Kohler

The V4L can get you there. With the same suspension and rear seats as lifted Onwards, this vehicle is outfitted with premium comfort and quality. Summer night rides and sunrise cruises are safer, thanks to automotive quality headlights, tail lights, & brake lights with optional turn signals.

  • Specifications
  • Warranty

Options

Description



Unit #: 25877

SN: EK2217281997



Includes:

  • 429 cc Kohler Engine - 14 hp EFI
  • Black Body Panels
  • Black Canopy Top w/ Grab Handles
  • Tinted Flip / Fold Windshield
  • Standard Beige Seats
  • Standard Suspension
  • 12" Black Chrome Aerion Wheels
  • 22" Kraken Tires
  • LED Light Kit
  • Flip / Fold Rear Seat
  • Alumicore Chassis
  • Dual Cupholders
  • Oil Light
  • Fuel Gauge
  • Hour Meter
  • 2 Year Factory Warranty
  • Keys




    CAN BE PURCHASED IN-STORE ONLY

    Power


    ELECTRIC

    HP

    HP LITHIUM

    GAS

    Motor / Engine

    250 Amp DC

    Motor Controller

    375 Amp DC

    Motor Controller

    375 Amp DC

    Motor Controller

    429 cc Kohler, Overhead Valve (OHV) with EFI

    Horsepower

    3.3 hp (2.4 kW) rated;

    Peak 13hp (9.6kW)

    22.4 hp (16.5 kW) Peak

    29 hp (21.4 kW) Peak

    14.0 hp (10.3 kW)

    rated @ 3600 RPM per SAE J1940

    Batteries

    (6) 8-Volt

    (6) 8-Volt

    58V Lithium-Ion (1)

    12-Volt (1)

    Charger

    E.R.I.C. Automatic, 48-Volt, UL and CSA listed

    E.R.I.C. Automatic, 48-Volt, UL and CSA listed

    48V 650W HF Li-Ion (Shelf / onboard): 48V 900W HF Li-Ion

    (Shelf only)

    N/A

    Speed Range

    19 mph (30 kph)

    19 mph (30 kph)

    19 mph (30 kph)

    19 mph (30 kph)

    Fuel Capacity

    N/A

    N/A

    N/A

    6.0 gal (22.7 L)

    Steering & Suspension


    ELECTRIC / HP / HP LITHIUM

    GAS

    Steering

    SportDrive -- Self-compensating double

    reduction helical rack & pinion

    SportDrive -- Self-compensating double

    reduction helical rack & pinion

    Front Suspension

    Independent A-arms with Hydraulic shocks

    Independent A-arms with Hydraulic shocks

    Rear Suspension

    Patent pending w/ Track Bar and Automotive Grade Jounce Bumpers

    Patent pending w/ Track Bar and Automotive Grade Jounce Bumpers

    Brakes


    ELECTRIC / HP / HP LITHIUM

    GAS

    Brakes

    Self-adjusting, rear wheel mechanical drum

    Self-adjusting, rear wheel mechanical drum

    Park Brake

    Foot actuated, 3-position

    Foot actuated, 3-position

    Body & Tires


    ELECTRIC / HP / HP LITHIUM

    GAS

    Body and Finish

    Front: Painted TPO; Rear: Painted Surlyn

    Front: Painted TPO; Rear: Pained Surlyn

    Tires

    22 x 10 - 10 Tubeless

    22 x 10 - 10 Tubeless

    LxWxH

    114 x 49 1/2 x 80 1/2 inches

    22 x 10 - 10 Tubeless114 x 49 1/2 x 80 1/2 inches

    Wheelbase

    67 1/2 inches

    67 1/2 inches

    Ground Clearance

    6 3/8 inches

    6 3/8 inches

    Tread-Front and Rear

    Front/Rear: 40 3/4 / 39 1/2

    Front/Rear: 40 3/4 / 39 1/2

    Total Vehicle Weight

    1125 lbs / 1125 lbs / 895 lbs

    875 lbs

    Frame Type

    AlumiCore -- Ladder-Style Aluminum Box Beam

    AlumiCore -- Ladder-Style Aluminum Box Beam

    Options

    Description



    Unit #: 25877

    SN: EK2217281997



    Includes:

    • 429 cc Kohler Engine - 14 hp EFI
    • Black Body Panels
    • Black Canopy Top w/ Grab Handles
    • Tinted Flip / Fold Windshield
    • Standard Beige Seats
    • Standard Suspension
    • 12" Black Chrome Aerion Wheels
    • 22" Kraken Tires
    • LED Light Kit
    • Flip / Fold Rear Seat
    • Alumicore Chassis
    • Dual Cupholders
    • Oil Light
    • Fuel Gauge
    • Hour Meter
    • 2 Year Factory Warranty
    • Keys




      CAN BE PURCHASED IN-STORE ONLY

      Power

      Motor / Engine

      (Electric) - 250 Amp DC

      Motor Controller

      (Electric HP) - 375 Amp DC

      Motor Controller

      (HP Lithium) - 375 Amp DC

      Motor Controller

      (Gas) - 429 cc Kohler, Overhead Valve (OHV) with EFI

      Horsepower

      (Electric) - 3.3 hp (2.4 kW) rated;

      Peak 13hp (9.6kW)

      (Electric HP) - 22.4 hp (16.5 kW) Peak

      (HP Lithium) - 29 hp (21.4 kW) Peak

      (Gas) - 14.0 hp (10.3 kW)

      rated @ 3600 RPM per SAE J1940

      Batteries

      (Electric) - (6) 8-Volt

      (Electric HP) - (6) 8-Volt

      (HP Lithium) - 58V Lithium-Ion (1)

      (Gas) - 12-Volt (1)

      Charger

      (Electric) - E.R.I.C. Automatic, 48-Volt, UL and CSA listed

      (Electric HP) - E.R.I.C. Automatic, 48-Volt, UL and CSA listed

      (HP Lithium) - 48V 650W HF Li-Ion (Shelf / onboard): 48V 900W HF Li-Ion

      (Shelf only)

      (Gas) - N/A

      Speed Range

      (Electric) 19 mph (30 kph)

      (Electric HP) - 19 mph (30 kph)

      (HP Lithium) - 19 mph (30 kph)

      (Gas) - 19 mph (30 kph)

      Fuel Capacity

      (Electric) - N/A

      (Electric HP) - N/A

      (HP Lithium) - N/A

      (Gas) - 6.0 gal (22.7 L)

      Steering & Suspension

      Steering

      SportDrive -- Self-compensating double reduction helical rack & pinion

      Front Suspension

      Independent A-arms with Hydraulic shocks

      Rear Suspension

      Patent pending w/ Track Bar and Automotive Grade Jounce Bumpers

      Brakes

      Brakes

      Self-adjusting, rear wheel mechanical drum

      Park Brake

      Foot actuated, 3-position

      Body & Tires

      Body and Finish

      Front: Painted TPO; Rear: Painted Surlyn

      Tires

      22 x 10 - 10 Tubeless

      LxWxH

      (Electric, HP, HP Lithium) - 114 x 49 1/2 x 80 1/2 inches

      (Gas) - 114 x 49 1/2 x 80 1/2 inches

      Wheelbase

      67 1/2 inches

      Ground Clearance

      6 3/8 inches

      Tread-Front and Rear

      Front/Rear: 40 3/4 / 39 1/2

      Total Vehicle Weight

      (Electric, HP, HP Lithium) - 1125 lbs / 1125 lbs / 895 lbs

      (Gas) - 875 lbs

      Frame Type

      AlumiCore -- Ladder-Style Aluminum Box Beam

      2 Year Warranty


      Warranty for New Equipment:


      Company warrants that new Equipment manufactured by Company and delivered hereunder will be free of defects in material and workmanship for the periods of time specified in the applicable limited warranty statements of Company for such Equipment, each of which is hereby incorporated herein by reference. Unless otherwise specified in writing by Company, aftermarket accessories will be free of defects in material and workmanship for six (6) months from the date of shipment and service parts will be sold “AS-IS”.


      Warranty for Used Equipment:


      To the extent that Purchaser is not the original purchaser of Equipment, COMPANY HEREBY REVOKES THE BATTERY PORTION OF

      THE ORIGINAL MANUFACTURER WARRANTY FOR EQUIPMENT WITH A MODEL YEAR MORE THAN ONE (1) YEAR OLDER THAN THE CURRENT EQUIPMENT MODEL YEAR, REGARDLESS OF ANY LANGUAGE TO THE CONTRARY CONTAINED WITHIN SUCH LIMITED WARRANTY STATEMENT OR ELSEWHERE, AND SUCH WARRANTY IS HEREBY MADE NULL AND VOID. ALL USED EQUIPMENT IS SOLD “AS-IS, WHERE-IS, WITH ALL FAULTS.” PURCHASER SHALL COMMUNICATE THIS CANCELLATION OF THE ORIGINAL MANUFACTURER’S WARRANTY TO PURCHASER’S CUSTOMERS IN ADVANCE OF THE SALE OF THE EQUIPMENT.

      Notwithstanding the preceding sentence, if the applicable sales invoice accompanying this contract affirmatively and definitively denotes that the Equipment is covered by a warranty, that warranty shall be Company’s standard pre-printed limited Remanufactured warranty in effect at the time of sale, a copy of which is available upon request (the “Applicable Warranty Statement”). All such warranty statements (as they may be modified or updated from time to time by Company) are hereby incorporated by reference.


      Warranty Generally:


      EXCEPT FOR THE FOREGOING WARRANTIES CONTAINED IN THE APPLICABLE SECTION 7, 8, OR 9 HEREOF (IF ANY) AND THE WARRANTY OF CLEAR AND MARKETABLE TITLE, COMPANY MAKES NO OTHER REPRESENTATIONS, CONDITIONS OR WARRANTIES EXPRESS OR IMPLIED AND ALL IMPLIED WARRANTIES, INCLUDING THOSE RELATING TO MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED.

      Purchaser shall be obligated to promptly report any failure to conform to the applicable warranty to Company in writing within the applicable warranty period, whereupon Company shall, at Company’s option, correct such nonconformity by suitable repair to such Equipment or furnish a replacement part

      FOB point of shipment, provided Purchaser has stored, installed, maintained, and operated such Equipment in accordance with reasonable industry practices and has complied with specific recommendations and the operator manual(s) of Company. Company shall not be liable for any repairs, replacements, or adjustments to the Equipment or any costs of labor performed by Purchaser or others without Company’s prior written approval.

      The effects of corrosion, erosion, and normal wear and tear are specifically excluded from Company’s warranty. Performance warranties, if any, are limited to those specifically stated within Company’s proposal. Unless responsibility for meeting such performance warranties is limited to specified shop or field tests, Company’s obligation shall be to correct in the manner and for the period of time provided in the applicable warranty.

      Correction by Company of nonconformities whether patent or latent, in the manner and for the period of time provided above, shall constitute fulfillment of all liabilities of Company for such nonconformities, whether based on contract, warranty, negligence, indemnity, strict liability or otherwise with respect to or arising out of such Equipment.
